6" Daylighter with Gravity® LED G6 Pair Pack System

SKU
gravity-led-daylighter
Availability: In stock

$479.99
KC's 6" Gravity LED Daylighter feature 20w LED bulbs in a SAE legal driving pattern. Black steel housing and polycarbonate lens with FLEXible base for easy aiming. Pair includes complete wiring harness, switches, and ABS stone guards.
FEATURES
-2 x 20W Gravity® LED G6 optical inserts
-Black Powder Coated Steel housing
-Hard Coated Polycarbonate Lens
-Driving Beam Pattern

LIGHT PERFORMANCE (PER LIGHT)
-Raw Lumens: 2,300 lm
-Lux @ 10 Meters: 1,310 lx
-Candela: 131,000 cd
-Beam Distance (Meters): 724m

SPECIFICATIONS (PER LIGHT)
-Wattage: 20W
-LED Source: CREE XPL HD LED
-Amp Draw: 1.63A
-Voltage: 9V-32V
-IP Rating: IP67
-Product Dimensions: W - 6.22" x H - 8.42" x D - 5.38"

PARTS INCLUDED
-(2) 20W 6" Gravity® LED Daylighter lights
-Deluxe Wiring Harness w/ 2-Pin weatherproof connectors
-(2) Protective KC Daylighter light Guards
-30A Illuminated Switch w/ Switch Panel

GRAVITY® GRD EXTREME OUTPUT AND EFFICIENCY
Gravity® Daylighters are powered by our G6 LED optical inserts which deliver an incredible 1,310 lx @10m using only 1.63A per light. Our patented GRD (Gravity® Reflective Diode) system aims the LEDs into the precision reflectors to capture all the light and project it forward.

AVAILABLE BEAM PATTERN AND ADVANTAGES
Driving Beam - SAE & ECE street legal beams provide added peripheral visibility and while reaching further than stock lights.

ADJUSTABLE MOUNTING FOR ACCURACY AND PRECISION
Our time-tested Daylighter shock mount system is resilient and allows users to accurately aim the lights ensuring beam stability and consistency.

RACE PROVEN STRENGTH & DURABILITY
The race-proven steel housing combined with our IP67 rated Gravity® G6 LED optical insert creates an extremely strong and durable combination that will withstand the harshest of environments and terrains.
More Information
SKU 0653
Weight 8.000000
Compliance DOT/SAE/ECE SAE J581, ECE R112 (Driving)
Wattage Per Light 20W
Total Wattage 40W
Amp Draw Per Light 3.3 a
Voltage 9V-32V
Lumens Per Light 2,300 lm
Lux Per Light 1,310 lx
Candela Per Light 131,000 cd
Light Temp 5000 K
Lens Color Clear
LED Color White
Beam Pattern Driving
Beam Distance 724 m
Light Technology LED
Mount Location A-Pillar / Ditch, Bumper, Overhead, Rear / Back-up
Size of Products 6"
Material Stainless Steel
Product Finish Black
Included Components 2 x Gravity LED™ Daylighter(Black Steel) SAE/ECE Driving Beam Light, Wiring Harness with Weatherproof Connectors, Illuminated LED Light Switch, 2 x 6" Protective KC Daylighter light Guards, Mounting Hardware
Color Black
Prop 65 No
Product Dimensions W - 6.22" x H - 8.42" x D - 5.38"
UPC 084709006532
IP Rating IP67
Product Data Sheets
pdf

0651 - 6" Daylighter Gravity® LED - Spot Beam - Pair

0653 - 6" Daylighter Gravity® LED SAE - Driving Beam - Pair

File Size: 611.5 KB
pdf

0651 - 6" Daylighter Gravity® LED - Spot Beam - Pair

0653 - 6" Daylighter Gravity® LED SAE - Driving Beam - Pair

File Size: 608.8 KB
Installation Guides
pdf

0651 - 6" Daylighter Gravity® LED - Spot Beam - Pair

0653 - 6" Daylighter Gravity® LED SAE - Driving Beam - Pair

File Size: 166.8 KB
video

0653 - 6" Daylighter Gravity® LED SAE - Driving Beam - Pair

Videos
video

0653 - 6" Daylighter Gravity® LED SAE - Driving Beam - Pair

video

0653 - 6" Daylighter Gravity® LED SAE - Driving Beam - Pair
