FLEX ERA® LED Light Bar - Master Kit
Info & Features
Info & Features
HIGH-OUTPUT PERFORMANCE
With 7,912 lumens of power per 10" segment, the FLEX ERA LED Bar sets a new standard in output, offering unprecedented visibility and beam quality—ideal for demanding, high-speed conditions.
FLEXIBLE DESIGN
The FLEX ERA LED Light Bar is linkable, curvable, and optic swappable, defying all engineering limits while staying true to the core elements of the FLEX ERA family. Whatever your lighting demands, this bar delivers.
CUSTOMIZABLE
Our time-tested FLEX family tradition ensures you can personalize your rig with KC's colored accent bezels. These bezels come standard in gold, but you can choose from deep red, rich blue, or gloss black to suit your style.
MASTER KIT
Guessing the best beam pattern is over. The FLEX ERA LED Light Bar Master Kit includes lights, both beam pattern lenses, spare o-rings, KC logo covers, and a complete wiring kit, so you spend less time in the garage and more time on the trails.
AMBER LED BACKLIGHT
The FLEX ERA LED Light Bar helps you stand out in the crowd thanks to its Amber LED backlight. This can be used on-road or off-road, day or night, adding an extra touch of style.
DESIGNED TO SHATTER EXPECTATIONS
FITMENT
It's crucial to verify that the off-road lights you're considering will fit and work with your vehicle. Whether you're using universal mounts or vehicle-specific kits, we've got you covered.
Universal Mounting
Our lights are designed to be universal and can work with mounts from other companies, including roof racks, aftermarket bumpers, and more. Ensure you have the proper specs for easy installation.
See Buying GuideVehicle-Specific Mounting Kits
For select vehicles, such as Jeeps, Fords, and UTVs, we offer specific brackets and mounts for easier installation. These kits ensure a perfect fit and a hassle-free setup.
See the OptionsNeed Further Assistance?
We're here to help.
If you're unsure about fitment or if our mounts will work for your vehicle, contact our KC experts by email or phone.
Contact UsI bought this light bar for my 15' Jeep jk after purchasing the 50” flex era LED bar. This 10” light bar puts out just the right amount of light (easily overwhelming) my high beam KC LED headlights. The wiring harness is the best I've seen with fully heat shrinked fittings and heavy gauge wire. Light bar comes with very robust hardware. It seems very well made and allows for attaching the wiring harness to the left or right side of the light bar which is convienant for vehicles that have their batteries mounted on the left or right side. I would definitely purchase this light bar again; to include the Flex Era 50” LED light bar which is absolutely insanely bright!!!!
Chad R.
Specs
Buying Guide
To select the perfect FE Bar for your vehicle, it's essential to consider a few things for optimal performance and fit. Here's a quick guide to help you decide what is best for your needs.
Recommended Sizes and Uses
- 10" or 20" Bar
- Best For: Front bumpers
- These compact light bars are ideal for providing excellent forward visibility without taking up too much space.
- 30" or 40" Bar
- Best For: Aftermarket roof racks or UTVs
- Perfect for mounting on aftermarket roof racks with wind fairing cutouts, the 30" or 40" bars offer sleek appearance with plenty of output.
- 50" Bar
- Best For: Overhead configurations
- Suited for overhead or roof-mounted setups, these deliver the maximum trail-illuminating brightness in a streamlined package.
How to Measure
To determine the appropriate size for your vehicle or mounts, measure the intended mounting location's width and compare it to the light bar's dimensions. Ensure there is extra space outside of the mounts hardware, typically an additional 0.5-1 inch on each side.
Installation Tips
- Check out our Vehicle Specific Kits to determine if we offer any mounts for where you want to mount your light bar.
- Double-check the mounting surface and ensure it is sturdy enough to support the light bar.
- If mounting overhead, consider using a Wire Hider to cleanly and securely route your wire harness up the windshield.
- To see more tips for light bars for Jeeps, check out our full guide here!
AVAILABLE BEAM PATTERNS Learn more about Beam Patterns
Combo Beam Lens
(1,610 lx)
Spot Beam Lens
(1,800 lx)
Popular Mount Locations
Power Draw
Have More Questions?
If you need assistance, not to worry, we're here to help.
INSTALLATION GUIDES CONTACT USWhat's in the Box
Any FE Bar from 10" to 50" comes standard as a Master Kit with absolutely everything you need to get up and running quickly so you can spend less time in the garage and more time out on the trails.
- 10" FLEX ERA® LED Light Bar (1 per segment)
- Combo Beam Lenses (pre-installed; 1 per segment)
- Spot Beam Lenses (1 per segment)
- Light Covers - Black with Yellow KC Logo (1 per segment)
- End Mounts, Linker Kits, and Hardware
- Assembly Tool Kit and Setup Guide
- Complete Wiring Kit with LED Switch
Accessories & Mounts
Installation
Installation Difficulty
Looking for installation advice? KC Academy offers comprehensive information on wiring, mounting, and installation options.
Explore our product guides or reach out to our KC experts, who can assist you every step of the way
Installation Videos
Frequently Asked Questions
Will the 20-50” FLEX ERA® LED Light Bars come pre-assembled?
No. Regardless of if you buy a 20”, 30”, 40” or 50” bar, they will not come preassembled. But don't worry! The inside of the box itself contains a full, true-to-scale assembly guide to ensure you get it done quickly. Even better - we included all of the tools necessary for installation. Grab a beer and get to work, it shouldn't take too long at all!
How do I link the segments together?
The ends of each 10” segment are universal in that they can accept either and End Mount Bracket or a Linker Bracket. Just make sure that you put the Overmolded Power Linker on prior to the main bracket! Use the included hardware and go snug without overdoing it.
How do I change the bar from straight to curved?
At each junction point of two 10” FE Bar segments, the linker bracket has two options for where to place the set screw that determines if the bar is curved or straight. Place the smaller countersunk bolts into the holes shown below on each junction to make it to your liking.
Is the FE BAR based on the FLEX ERA 1 or FE4?
Not exactly. While it might look similar in size to the FE1, it's an entirely new product. The bezels and shields are not interchangeable. In fact, the FE Bars have very similar performance to a single FE4 light due to the use of similar optic components, just in a different configuration. This product is a complete reimagination of the previous FLEX Array Bar, that stays true to the FLEX ERA Family of products.
What are the extra lenses that are included in the FLEX ERA® LED Light Bar boxes?
Each box of FLEX ERA® LED Light Bars lights come standard as a Master Kit, which includes all beam pattern lenses that are available. The lights come preassembled with the Combo Beam lenses (vertical lines ends of the lens). There are also Spot Beam Lenses (complete clear appearance) included in the kit.
When should I use the included spot beam or combo beam lenses?
For those that desire the furthest possible distance out of their light output, the Spot Beam lenses will perform best. For those that want short to mid-range distance coverage while also having more horizontal coverage, the pre-assembled Spread Beam lenses will be best.
Since the lens is designed to be swappable, how does this impact the warranty should anything happen? E.g. if water ingress occurs due to user error while swapping the lens?
Our standard KC Adventure Further Guarantee applies to these lights. We encourage you to swap out your lenses to see what works best for you - just do so in a clean and controlled environment. Feel free to check out our installation videos for best practices or give us a call and we'll be happy to assist!
What are the differences between the Amber Shields and the Performance Yellow Lenses?
While both enhance visibility in poor visibility conditions, Amber Shields will excel in extreme conditions like highly dense dust or silt, with their darker hue minimizing glare. On the other hand, our Performance Yellow Lenses offer a purer, brighter yellow output, making them great for a broader range of conditions from dust to wide-open and clear environments. In addition, the Amber shields simply snap over the face of the light, while the Perf Yellow Lenses will entirely replace the clear spot or combo beam pattern lens. Combo Clear and Spot Clear lenses come with the Master kit. All Performance Yellow lenses are sold separately.
What is the difference between the FLEX ERA® LED Light Bars and the discontinued FLEX Array Light Bars?
- The FLEX ERA® LED Light Bar is the replacement for the discontinued FLEX Array Light Bars. We took sizing, styling, and feature-set cues from the original, and evolved the light in every single way possible.
- A single 10” FE Bar features 108W and 7,912 lumens of output compared to the older FLEX Bar which was 50W and 4,875 lumens per light.
- The FE Bar is fractionally larger in all 3 dimensions than the FLEX Array was, allowing for deeper and larger reflectors for groundbreaking performance.
- Finally, the FLEX ERA® Bar features an Amber LED Backlight for a bit more styling.
Are there options for colored bezels beyond the gold one on FE Bars?
Absolutely! Customization and personalization is as core to the FLEX ERA Family as performance is. We also offer the bezels in 10” segments of red, blue, and black bezels.
Do the FE Bars include an amber backlight?
Yes. The FLEX ERA® Bar still has the main power circuit for the full brightness mode, and also uses a second power circuit to offer the Amber Backlight.
Do the FE Bars include blackout covers?
Yep!
Can I use light locks with the FE Bar?
Yes, light locks are compatible with the FLEX ERA® LED Light Bars. Use SKU 7222 aka the M8-1.25 Light Lock Security Nut Set for the main end mount, and SKU 7223 aka the M10-1.5 Light Lock Security Nut Set for the bottoms of the L-Brackets. But remember, don't lose the included key! Otherwise you'll have a fun evening with an angle grinder if you ever need to remove the lights.
Can I customize my FLEX ERA covers?
Absolutely! See our support article with links to templates.
